README

This is a javascript floorplanner tool based on the existing typescript based project blueprint3d

DEMO

Cick for example

DOCS

Yes, the initiative has begun for the documentation. Of late I have been getting inquiries on using this framework. It is time to have the documentation rolling docs

DEMO VR

The ability to export the floorplan as GLTF gives the scope of having easy VR with A-Frame. Export the layout to use it directly with A-Frame or process it further using Blender and then use it with A-Frame.

Cick for example of VR - 1 VR - 2

You will notice a lot of flickering in the VR mode. This is because of the overlapping materials in the floorplan.

What is this?

This is a customizable application built on three.js that allows users to design an interior space such as a home or apartment. Below are screenshots from our Example App (link above).

1) Create 2D floorplan:

floorplan

2) Add items:

add_items

3) Design in 3D:

3d_design

Developing and Running Locally

To get started, clone the repository and ensure you npm >= 3 and rollup installed, then run:

npm install
rollup -c

The latter command generates build/js/bp3djs.min.js from src.

The easiest way to run locally is to run a local server from the build directory. There are plenty of options. One uses Python's built in webserver:

cd build

# Python 3.x
python -m http.server

Then, visit http://localhost:8000 in your browser.

Contribute!

This project and the original project requires a lot more work. If you are someone like yodha of typescript then kindly visit the original project, the author is a wonderful human being who facilitated this idea, efforts, and materials in the first place. Else you are someone like me who likes to play around with es6 then you can use this one.

Please contact us if you are interested in contributing.

Todos and hurrays on completed ones

Directory Structure

src/ Directory

The src directory contains the core of the project. Here is a description of the various sub-directories:

core - Basic utilities such as logging and generic functions

floorplanner - 2D view/controller for editing the floorplan

items - Various types of items that can go in rooms

model - Data model representing both the 2D floorplan and all of the items in it

three - 3D view/controller for viewing and modifying item placement

Notes about changes from the original
